• Technical Specification

Camera:-

• Image Sensor: 1/3’’ Progressive Scan CMOS
• Min. Illumination: Color: 0.008Lux @F1.2, B/W: 0Lux with IR on
• WDR: Super WDR up to 120dB
• Lens: 3.6mm
• Field of View: H74°
• Shutter Time: 1/100000s~1/5s
• IR Distance: Up to 20m
• Day&Night: ICR Filter Auto Switch

Video:-

• Max Image Resolution:  2592*152020fps(2592×1520),
• Frame Rate: 25fps(2304×1296),  25fps(1920×1080), 25fps(1280×960), 25fps(1280×720), 25fps(704×576)
• Video Compression: H.265(HEVC)/H.264/MJPEG
• Video Bit Rate: 16Kbps~16Mbps(CBR/VBR Adjustable)
• Image Setting: Brightness/Contrast/Saturation/Sharpness

Network:-

• Ethernet: 1*RJ45 10M/100M Ethernet Port
• Network Storage: NAS(Support NFS, SMB/CIFS)
• Protocol: TCP/IP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP,UPnP, SIP, IPv6, PPPoE, VLAN

System:-

• Storage: Support Micro SD/SDHC/SDXC, up to 64G
• Advanced Function: Motion Detection, Privacy Masking, Backlight Compensation, 3D-DNR, ROI
• SIP/VoIP Support: Yes, Voice & Video-over-IP
• Event Trigger: Motion Detection, Network Disconnection, etc.
• Event Action: FTP Upload/ SMTP Upload/ SD Card Record/SIP Phone
• System Compatibility: ONVIF Profile S

General:-

• WDR: Supported (120dB)
• Power Supply: PoE/ DC12V±10%
• Power Consumption: 5.5W MAX, 9.5W MAX (With IR on)
• Weather Proof: Up to IP67 Rating for Weather-resistant
• Weight: 765g
